AT-10K: Automatic identity document authentication solution
AT-10K: Automatic identity document authentication solution
The AT-10K cover can be removed to more easily scan documents larger than ICAO ID-1 documents.
The AT-10K cover can be removed to more easily scan documents larger than ICAO ID-1 documents.
The spine clip allows for easy and effective scans of inflexible passports and other documents.
The spine clip allows for easy and effective scans of inflexible passports and other documents.
at10k-dimensions
AT 10k dimensions

AT10K



The AT10K is an identity document scanner used to capture images and data from driver license-sized (ICAO ID-1) as well as other larger format documents (ICAO ID-2 and ID-3) for use with the PALIDIN™ ID Document Authentication software:
  • More than 1,100 US state-issued Identification Documents (e.g. Driver Licenses & Identification Cards)
  • Federally-issued Identification Documents (e.g. Passports, Military IDs, Green Cards, TWIC cards, Congressional ID's,)
  • Foreign Government-issued Identification Documents (e.g. Passports, driver licenses & national ID cards)



Advantages and key features:
  • A simple process: Place the identity document on the reader at any angle and the AT10K does the rest!
  • Ability to integrate data via Software Development Kit (SDK)
  • Checks multiple data and security points on identity documents in both visible and infrared (IR) light



AT10K



Verification Types

• ICAO ID-1, ID-2, and ID-3 Documents
• 1D and 2D Barcodes


Power Supply

• 5 volts DC, 500mA (USB 2.0)
• 100 - 240 VAC +/- 10%, Frequency 47 - 63 Hz (detachable AC power cable)


Host PC Requirements

• CPU: Intel Only: Intel Core i5 (minimum 2 GHz)
• Operating System: Windows 10 Pro 64 bit or 11 Pro 64 bit
• Ram: 8 GB
• Disk Space: 128 GB
• Interface: USB 2.0

Dimensions

• Width: 6.3" (16.0 cm)
• Height: 2.6" (6.5 cm) without hood; 4.0" (10.3 cm) with hood
• Depth: 7.4" (18.7 cm)


Net Weight

2.46 lbs (1.1 kg)


Light Bands

Visible, Infrared, Ultraviolet (UV)

Image Resolution

370dpi & 700 dpi options

FAQ

What types of documents can the AT10K authenticate

The AT10K is designed for authenticating identification documents. Specifically, it is designed to automatically identify and authenticate ID-1, ID-2, and ID-3 documents, which are international (ICAO) standard-sized ID documents. ID-1 documents are driver license-sized; examples include drivers’ licenses, state ID cards, military ID’s, Green cards, voter registration cards, diplomatic cards, passport cards. ID-2 documents are slightly larger than ID-1 documents; examples include visas and the French identity card. ID-3 documents are even larger than ID-2 documents; passport booklets are the most commonly used ID-3 document.

What environments can the AT10K be used in?

The AT10K is designed to optimally perform in well-lit environments where space is limited. The AT10K was recently updated to have a new stylish look that will fit into the décor of most customer-facing service desks.

Note: A Windows-based PC is required for standard installations. Custom installations allow the use of thin clients in the .NET framework with centralized processing of licenses and data at server-level.

We currently have a mobile ID Authentication solution, MobilVerify, in beta. If you would like to try the beta version MobilVerify for free, please fill out the form on this page.

How does the AT10K work?

The AT10K is a hardware/software platform that captures high-resolution, full color images of ID documents using both natural and infrared sources. The device also “reads” information from magnetic strips, barcodes, smart-chips, RFID chips and digital watermarks.

After the AT10K captures the images and the data, the PALIDIN™ software application performs multiple security checks using a comprehensive database of ID documents. Multiple points on the document are checked to make certain that proper manufacturing technique was used, and that the document itself contains the proper design elements. The data captured from different locations on the document are cross-checked to make sure that information such as name, birth date, issue date, expiration date, etc. all match.

When the application is finished, it will display either a “pass” or “fail” grade.

Data and images captured from the ID document may be treated by the user. The PALIDIN™ Software Development Kit enables customization of the data management, including potential exporting of the data to third-party databases and core enterprise applications.



What comes with the AT10K when I buy it?

A power cord to connect your AT10K to an external power supply
• A USB cord to connect your ID-150 to a PC
•  Information about your PALIDIN™ software license key and an owner's manual (PDF) that includes a quick set-up guide

Warranty Info


The AT10K hardware device comes with an included one-year full service warranty which includes depot service. Additional years are also available for purchase.

The purchase of a PALIDIN™ software license includes 12 months of software and document library updates to maintain the highest level of assurance for our customer. Annual renewals are available, and may be purchased in-advanced.
